# Simple GnuPLoTting

*posted by vyzo*

gnuplot is a very powerful and widely used interactive data plotting program. It can generate two-dimenational and three-dimensional surface plots, either on screen or print to files with a wide-array of supported formats. If you are not familiar with it, you can get an idea of its capabilities here

A new package, gnuplot.plt, is now available on planet which allows you to programmatically interact with gnuplot processes and generate plots on the fly. The package provides a simple interface that abstracts gnuplot’s quirky syntax and takes care of data marshalling using temporary files.

Without further ado, here is to every computer scientist’s favorite growth curves:

(require (planet vyzo/gnuplot)) (define gplot (gnuplot-spawn)) (define data (gnuplot-data (build-list 90 (lambda (x) (let ((x (add1 (/ x 10.)))) (list x (log x) (* x (log x)) (expt x 2) (expt 2 x))))))) ;; png output options (define png '(png enhanced transparent font (str arial))) ;; on screen plot (gnuplot-set gplot '(title (str "growth curves"))) (gnuplot-plot gplot #:range '(() (1 1000)) (gnuplot-item data '(using (seq: 1 1) title (str "x") with line)) (gnuplot-item data '(using (seq: 1 2) title (str "log(x)") with line)) (gnuplot-item data '(using (seq: 1 3) title (str "xlog(x)") with line)) (gnuplot-item data '(using (seq: 1 4) title (str "x^2") with line)) (gnuplot-item data '(using (seq: 1 5) title (str "2^x") with line))) ;; replot to png (gnuplot-hardcopy gplot "/tmp/grow.png" #:term png) ;; redo with logscale (gnuplot-set gplot '(logscale y)) (gnuplot-replot gplot) (gnuplot-hardcopy gplot "/tmp/loggrow.png" #:term png)
